Optimizacija mašinskih parametara za bolji kvalitet i manje habanja
Izazov
Neispravna geometrija alata jedan je od najčešćih uzroka neispravnih delova. Međutim, alatna mašina takođe ima veliki uticaj na proizvodni proces. Prese koje se koriste za štampanje i oblikovanje lima kontrolišu se pomoću različitih parametara mašine. Faktori kao što su kontaktni pritisak koji deluje na deo, podmazivanje i sila držanja koja fiksira deo tokom proizvodnje, utiču na konačni oblik dela.
Neoptimalno podešeni parametri prese mogu dovesti do nepravilnog kretanja prese tokom procesa oblikovanja. Ovo rezultira lošim kvalitetom dela i prevremenim trošenjem alata.
Rešenje
Pomoću sistema ARAMIS, korisnik može da zabeleži takva kretanja prese i alata kao 3D krivu. Ova merenja pružaju informacije o krutosti, vibracijama, oscilacijama, naginjanju, putanji kretanja mašine i pomeranjima između delova alata. Izmerni podaci se mogu koristiti za izvođenje analiza sposobnosti mašine i za određivanje parametara prese koje je potrebno optimizovati da bi presa radila optimalno.
Na ovaj način, ARAMIS pomaže u proizvodnji delova sa ispravnom geometrijom i sprečava prekomerno habanje alata.
